Enclosed Power Pack
Heavy duty chain and sprocket mechanism
Adjustable Platform Chains
Self lubricating bushes on all pivot points
Modular design for easy maintenance
Heavy duty wear pads in columns
External 2 button controls with internal toggle switch
Specifications
- Maximum Lifting capacity: - 750 kg
- Platform Construction: - Steel
- Platform Width: - 2200 mm (dependant on body dimensions)
- Platform Depth: - 1100 mm (dependant on body dimensions)
- Dead Weight: - +- 300kg
Specifications
- Maximum Lifting capacity: - 1000 kg
- Platform Construction: - Steel
- Platform Width: - 2400 mm (dependant on body dimensions)
- Platform Depth: - 1150 mm (dependant on body dimensions)
- Dead Weight: - +- 320kg
Specifications
- Maximum Lifting capacity: - 1500 kg
- Platform Construction: - Steel
- Platform Width: - 2400 mm (dependant on body dimensions)
- Platform Depth: - 1150 mm (dependant on body dimensions)
- Dead Weight: - +- 320kg
